how to remove discolor salt and stones from salt? Salt color sorter

how to remove discolor salt and stones from salt? Salt color sorter

    • how to remove discolor salt and stones from salt? Salt color sorter
    • how to remove discolor salt and stones from salt? Salt color sorter
    • how to remove discolor salt and stones from salt? Salt color sorter
  • how to remove discolor salt and stones from salt? Salt color sorter

    Product Details:

    Place of Origin: Hefei ,China
    Certification: CE,3C,ISO9001,IS014001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: 15000-100000USD
    Packaging Details: vacuum packing and wooden case
    Delivery Time: 10 days
    Payment Terms: TT/LC, D/P, Western Union, L/C, MoneyGram
    Supply Ability: 5000 sets per year
    Contact Now
    Detailed Product Description
    Sorting Accuracy: 99.99% Material: Stainless Steel
    Application: Sorting Salt And Removing The Defectiveness FPGA: ALTERA From USA, SAMSUNG Chip From Korea
    CCD Sensor: Toshiba From Japan Air Filter: SMC From Japan
    Light Source: Digital Control LED Warranty: One Year

    how to remove discolor salt and stones from salt?


    how to remove discolor salt and stones from salt? Salt color sorter
    The optical sorter has great performance in sorting sea salt and rock salt.It can remove discolor salt ,stones and other foreigh material.
    Benefits of Salt Color Sorter
    1,Inexpensive sorting of various kinds of salt by color and brightness is possible
    Slightest color and brightness differences,for example white/light and dark grey as for anhydrite or slightly brown shades as for sulphur,are relibaly detected and are available as sorting parameters.
    2,The material yield is maximised by accurate detection and exact sorting.
    3,Effective corrosion protection with special powder coating as well as the use of special stainless steel ensure long-term operation with long endurance.
    4,Maximizing yield

    The high precision ejection system minimizes false reject of good grain, delivering a highly concentrated reject stream
    Due to minimal loss of good grains on the first pass, most grain applications do not require a re-sort while still running on a high capacity, however, a re-sort option is available if required




    Specification of Salt color sorter

    Model HKY1680-1G
    Channels 384
    Chute 6
    Salt size 8-120 mesh
    Throughput(T/H) 8-16
    Sorting Accuracy (%) >99.97
    Optimized carryover(bad: good) >8:1
    Channels preset for primary sorting and re-sorting 256:128
    Voltage (V) ~220(50Hz)
    Power of the main machine (KW) 2.2
    Air Pressure (MPa) 0.6~0.8
    Air Consumption (m³/min) <2.5
    Weight (Kg) 850
    Dimension (L x W x H)(mm) 1920×1410×2040






    salt sorting sample
