Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts

Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts

    • Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts
    • Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts
    • Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts
    • Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts
  • Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts

    Product Details:

    Place of Origin: Hefei ,China
    Certification: CE,3C,ISO9001,IS014001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: 0-80000USD
    Packaging Details: Wooden case and vacuum packing
    Delivery Time: 10 days
    Payment Terms: TT, L/C, T/T, D/A, D/P, Western Union, MoneyGram
    Supply Ability: 5000 sets per year
    Youtube video: https://www.youtube.com/watch?v=7YI9zvVwCdI
    Contact Now
    Detailed Product Description
    Application: Sorting Nuts By Color And Shape Sorting Accuracy: 99.99%
    CCD Camera: RGB,5400 Pixels CCD Sensor: Toshiba From Japan
    Air Filter: SMC From Japan FPGA: ALTERA From USA, SAMSUNG Chip From Korea
    Light Resource: LED Light ,digital Control Aftersale Service: Engineers Available To Service Oversea,on Site Commissiong And Training
    Warranty: One Year

    Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts



    Some advantages of Zhongke Color Sorter



    Full color Trichromatic sorting-Optical sorter

    1,1 to 16 chutes

    To meet and satisfy any production capacities.

    2,Ultimate full color RGB camera

    Front and rear optical system, composed by 4096 pixel RGB full color cameras, allows to identify any defect at 360°perspective

    with a resolution of 0.1mm.

    Defect size can also be controlled and adjusted according to needs.

    3,Shape size sorting integrated into the system

    Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts

    Size: Under and over sized objects for greater value

    Shape: Misshapen product and foreign material of the same color

    Color: Color defects by individual or combined defect area

    4,LED-lightning system

    Exclusively designed , LED lighting system allows the most precise focusing of the beam on the inspection line.

    5,User friendly setting with image acquisition
    Program setting and adjustment are performed through a user–friendly software which allows the acquisition of the product image to easily establish the defective elements to sort out.

    Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts

    6,Reliable electronics hardware

    The hardware is organized in easily replaceable electronic boards,

    using the ultimate FPGA technology;

    Self-control functions, such as auto-diagnosis and auto-calibration are standard on any sorters;

    Back-up of the operating software by USB on board.

    The high speed signal elaboration and communication to expulsion system allows an excellent performance.

    ALTERA company's high-speed FPGA processing from USA

    SAMSUNG chip from South Korea

    TOSHIBA camera sensor from Japan

    SMC air filter from Japan

    Schneider air switch and button switch from France

    Mean Well power supply from Taiwan

    MATRIX ejector from Italy(optical)

    Nuts Color Sorting Machine,optical sorting solution for many kinds of nuts



    Zhongke provides optical sorting solutions for grain processors who demand the highest standards of grain quality with a focus on food safety and maximizing yields.



    Improving food safety and delivering the highest quality grain

    Zhongke optical sorting solution improves food safety by removing diseased grains contaminated with toxins such as mycotoxins (e.g. vomitoxin (DON or alkaloids e.g. ergot)

    Excellent results in removing foreign seeds and grains from product (e.g. vetch, weed seed and others)

    optical sorters help achieve excellent intermediate product appearance, for products such as whole grain, grits and flakes



    Maximizing yield

    The high precision ejection system minimizes false reject of good grain, delivering a highly concentrated reject stream

    Due to minimal loss of good grains on the first pass, most grain applications do not require a re-sort while still running on a high capacity, however, a re-sort option is available if required



    Delivering high capacity solution

    Zhongke optical sorters can be individually configured to cater for capacities of between 500kg and up to 20 tonnes per hour (e.g. on wheat)

    Production volume is maintained, with minimum downtime for cleaning or product configuration change



    Consistent performance and lower operation costs

    Zhongke optical sorters deliver stable and reliable operation with product-tracking, auto-calibration and wiping of the viewing area, meaning machines are self-optimizing and perform consistently in the long-term





    Belt color sorter series specification



    capacity(t/h) 0.5-1.0 1.0-3.0 1.0-3.0
    Structure belt width 600mm
    single belt
    belt width 1200mm
    single belt
    belt width 1200mm
    double belt
    Cameras CCD camera
    5400 pixel
    CCD camera
    5400 pixel
    CCD camera
    5400 pixel
    Light LED light source LED light source LED light source
    Power(kw) 2 3 4.5
    Voltage(V) 110-250V/50-60Hz 110-250V/50-60Hz 110-250V/50-60Hz
    Sorting accuracy 99.99% 99.99% 99.99%
    Rejection rate(bad:good) ≧10:1 ≧10:1 ≧10:1
    Dimension(mm) 3565*1200*2110 3500*1800*2110 3565*1800*2900
    Air pressure(Mpa) 0.6~0.8 0.6~0.8 0.6~0.8
    Weight(kg) 600 800 1200
