Products highlights – High performance multiplex valves

Products highlights – High performance multiplex valves

Products highlights – High performance multiplex valves

Product Details:

Contact Now
Detailed Product Description

850 & 890(new) SERIES 2/2 NC Modular architecture: 1, 3 or 9 outlets Flow rate: from 100 l/min up to 1600 l/min Response time: down to 1 ms Pressure range: 2-8 bar Electrical connection: IP62 moulded-in cables Footprint: 46x46 mm Weight: 160 - 260 gr (depending on models) Variable flow rate versions for improved flexibility

Products highlights – High performance multiplex valves

580 SERIES 2/2 NC Modular architecture: 8 outlets Flow rate: 180 l/min each outlet Response time: down to 2 ms Pressure range: 0-5 bar Electrical connection: IP62 moulded-in cables Footprint: 118x28 mm Weight: 400 gr (depending on models) Sub-base versions for manifold installation available Variable flow rate versions for improved flexibility

Products highlights – High performance multiplex valves

750 SERIES 2/2 NC and 3/2 NC or NO Modular architecture: 8 outlets Flow rate: from 50 l/min up to 700 l/min depending on outlets configuration Response time: down to 2 ms [max freq. up to 300 Hz] Pressure range: 0-8 bar Electrical connection: IP62 moulded-in cables, Easy Connection System Footprint: 55x55 mm Weight: 350 gr (depending on models) Variable flow rate versions for improved flexibility Custom configurations (3/3 and 5/2) available

Products highlights – High performance multiplex valves
