Place of Origin: | Hefei,China |
Certification: | CE,3C,ISO9001,IS014001 |
Model Number: | Z-1 to 16 |
Minimum Order Quantity: | 1 |
---|---|
Price: | 25000-100000USD |
Packaging Details: | Wooden case and vacuum packing |
Delivery Time: | 10 days after down payment |
Payment Terms: | TT, L/C, D/A, D/P, Western Union, MoneyGram |
Supply Ability: | 5000 |
Sorting Accuracy: | 99.99% | CCD Sensor: | Toshiba From Japan,5400 Pixels |
---|---|---|---|
Air Filter: | SMC From Japan | FPGA: | ALTERA Processor From USA |
Light Source: | LED Digital Control | Application: | Sorting Peanut Kernel And In Shell By Color And Shape |
Warranty: | One Year |
A reliable partner for integrated solutions. Effective grain sorting to increase profitability.
We provides optical sorting solutions for grain processors who demand the highest standards of grain quality with a focus on food safety and maximizing yields.
The Zhongke color sorters is suitable for small, medium or large-scale processing and is able to meet for a wide variety of grain applications.
What we can do?
Our Peanut Color Sorting Machines are able to sort white peanuts ,red peanuts ,peeled peanuts and peanut in shell,raw,balanched and roasted peanuts.The machine can detect and remove visible defects such as stones,grass,nut grass,stalks,stems,raisins,shells,discoloration,soy,bones,wood,corn,glass,and in shell as well as invisible to the human eye defects such as aflatoxin.
Color sorting for peanut kernel
Sorting solution for peanut in shell
Specification
Model | ZL-1 | ZL-3 | ZL-5 | ZL-7 | ZL-8 |
Channels | 64 | 192 | 320 | 448 | 512 |
Power(kw) | 0.8 | 1.8 | 2.6 | 3.5 | 4 |
Voltage(V) | 110-250V/50-60Hz | 110-250V/50-60Hz | 110-250V/50-60Hz | 110-250V/50-60Hz | 110-250V/50-60Hz |
Sorting accuracy | 99.99% | 99.99% | 99.99% | 99.99% | 99.99% |
Rejection rate(bad:good) | ≧10:1 | ≧10:1 | ≧10:1 | ≧10:1 | ≧10:1 |
Dimension(mm) | 960*1630*2050 | 1610*1630*2050 | 2225*1290*1710 | 2980*1630*2050 | 3350*1630*2050 |
Air consumption(L/M) | 400-800 | 800-1600 | 1300-2200 | 1800-3600 | 2000-4000 |
Weight(kg) | 210 | 600 | 880 | 1150 | 1400 |
Standard procedure of color sorter’s operation can be described as follows.
Input product is loaded in the sorter via in-feed hopper.With the help of vibration the material flows along the chute to the distribution channels.Then the product gets into the inspection zone,where it is checked by the high-tech sensors or CCD-cameras.Cameras ,having received the reflected light from the selected material,generate electric signal for computer operating system.
Depending on the signals received from the optical system,the computer control system sends the command to open the pneumatic valve(the ejector)which blows away grains different in color.The good product directly flows into the goods product hopper.The reject is blown off to the discharging hopper.
Most of the sorters have the re-pass option ensuring more accurate sorting of the grain and minimizing losses of the good product.
using the ultimate FPGA technology;
Self-control functions, such as auto-diagnosis and auto-calibration are standard on any sorters;
Back-up of the operating software by USB on board.
The high speed signal elaboration and communication to expulsion system allows an excellent performance.
ALTERA company's high-speed FPGA processing from USA
SAMSUNG chip from South Korea
TOSHIBA camera sensor from Japan
SMC air filter from Japan
Schneider air switch and button switch from France
Mean Well power supply from Taiwan
MATRIX ejector from Italy(optical)
Peanut Color Sorting video on YouTube channel
https://www.youtube.com/watch?v=H-M5C5V9qZA
https://www.youtube.com/watch?v=3Zl8AkSR1Zg
