Place of Origin: | China |
Certification: | CE,3C,ISO9001,IS014001 |
Model Number: | FX4805-BS |
Minimum Order Quantity: | 1 |
---|---|
Price: | 15000-150000USD |
Packaging Details: | Vacuum packing and Wooden case |
Delivery Time: | 10 days |
Payment Terms: | TT, D/A, D/P, Western Union |
Supply Ability: | 5000 per year |
Application: | Xray Optical Sorting | Sorting Accuracy: | 99.99% |
---|---|---|---|
Filter: | SMC From Japan | FPGA: | ALTERA Processor From USA, SAMSUNG Chip From Korea |
After-sales Service: | Engineers Available To Service Oversea | Warranty: | One Year |
Features
1. Innovate the single-spectrum technology of traditional X-ray machines, and use the world's first three-spectrum X-ray technology to redefine foreign body detection.
2. Taking into account both high-density malignant impurities and low-density malignant impurities
3. Equipped with a new generation of FPGA smart chips, more accurate recognition algorithms, easy processing of high-definition pictures, rapid capture of foreign objects, and simultaneous identification of all kinds of malignant impurities.
4. Using 64-channel high-frequency solenoid valve, fast response speed, high rejection accuracy, switching frequency up to 1000 Hz, greatly reducing loss, life cycle more than 10 billion times, ensuring lifetime use and reliable operation.
5. The use of special anti-radiation alloy materials and high-precision anti-radiation structure keeps the radiation dose at the level of the natural body (0.1-0.2uSv/h) far lower than the national standard 2.5uSv/h.
6. Integrated design of host and rejection device, reliable operation and convenient installation
Application
The machine could effectively detecting and removing conventional high-density malignant impurities mixed in bulk materials (such as pumpkin seed kernels, sunflower seed kernels, cashew nuts, peeled peanuts, etc.), such as metal, glass, Stones, etc., can also remove low-density malignant impurities such as branches, cigarette butts, plastics, and mouse poop. In addition, the unhulled kernels and shells in the shelled nuts can also be effectively detected and eliminated.
Model | IX4805-BS-B |
Sorting accuracy | SUS ball≥0.3mm,SUS wire≥0.2X2mm |
Power | 3.6kw |
Belt width | 480mm |
Weight of machine | 850KG |
Pressure | 0.6-0.8Mpa |
Air consumption | <2800L/Min |
X-ray radiation dose | <0.5uSV/h |
Radiation permit | A0379 |
Dimension(L*W*H) | 2720*1178*2121 |
Application for high density foreign material
Application for low density foreign material
