|Place of Origin:||China|
|Minimum Order Quantity:||1|
|Packaging Details:||Wooden case and vacuum packing|
|Delivery Time:||10 days|
|Payment Terms:||TT, L/C, D/A, D/P|
|Supply Ability:||5000 sets per year|
|Application:||Sorting Rice||Sorting Accuracy:||99.99%|
|FPGA:||ALTERA From USA, SAMSUNG Chip From Korea||Camera Sensor:||Toshiba,5400 Pixels|
|Filter:||SMC From Japan||Warranty:||One Year|
Our rice colour sorter machine is ideal for rice processors who sort different varieties of rice and at different processing stages.The sorting range is suitable for processors who demand the highest in rice quality,offering precision sorting to maximise yields and increase profits.
Raw rice sorting:
It can effectively removes both typical and challenging defects and foreign material;discolouredgrains,chalky grains,bran streaks,sticks,stones and unwanted foreign seeds,leaving the finished sort ,clean,and safe.
White rice sorting:
we can sort out red,yellow,and green grains,chalky rice,discolored and immature rice,blackspotted grains with spot less than 0.25mm.
Parboiled rice sorting
We can sort out black and burned grains,discolored ,black spotted.And any others defective grains.
Rice Color Sorter Machine working principle
The raw rice is milled in the milling plant, processed by the paddy boiling unit, dryer, destoner, husker, huller /sheller and then the produced final rice is taken to the color sorter machine. In this stage, the mixture raw rice will go into the hopper on top of the machine by elevator and then the rice will flow down along the chutes of color sorter machine. Chutes of colour sorting machine will make rice flow streamlined and consistent for scanning by CCD sensors in optical area, The moment the cameras detect any discolour, the camera instructs the ejectors fitted in the machine to open the nozzle. The nozzle is connected to air valves containing compressed air. This air is then used to shoot out the color defected material from the input rice. The types of defects in rice are: black tipped chalky, yellow, mouse droppings, immature grain, etc.
Some advantages of our Rice Color Sorter
1,Near human eye vision color sorting technology, using 16 million colors, brings the best sorting performances
2,Full-color cameras optical system, with dimensional control of the defects, allows 0.1mm optical resolution
3,image acquisition allows the easy and accurate setting of the defects to remove. Software adjustment is completely automatic thanks to HSV technology
4,Shape-sizing integrated into the system
5,Most concentrated rejects, thanks to customized hi-tech ejectors
6,Highest production capacities, automatically regulated by a feeder control device
7,Possibility to have simultaneous product resort, even with reverse sorting and third sorting.
8,Possibility to add sloping chutes for sorter upgrading or production increase
9,Possibility to install additional cameras operating in NIR after machine installation at working premises
10,Led lighting system which is digital control
11,Automatic cleaning system, with adjustable frequency and duration
12,Tilting optical boxes, to allow an easy internal access for maintenance operations
13,Airtight optical boxes with controlled temperature
14,Designed mechanics grants the highest hygiene and prevents product outflow or accumulation
15,Provision with de-dusting suction systems
16,14-inches display with full-color and multilingual touch-screen
17,Flexible and user-friendly
18,Reduced electric and compressed air consumption.
20,Use best quality components to ensure excellent quality.
21,From one chute to sixteen chutes to meet any different production capacity requirement.
Rice Color Sorter Machine specification
|Rice color sorter model||RC-1||RC-2||RC-3||RC-4||RC-5||RC-6||RC-7||RC-8||RC-10||RC-12|
Remark:We have many models from 1 chute to 16 chutes for option to meet any different production capacity.
rice color sorting samples
